Scorpion Racing

SBF Trickflow High Port Shaft Mount Rocker Arms Set

SBF Trickflow High Port Shaft Mount Rocker Arms Set

Our Price:
Regular price $1,367.18
Regular price Sale price $1,367.18
Sale Sold out
Ford,V8,289-302-351W
Part Number : 3722
Ratio
Offset
View full details

Description

3722 1.7 SBF Trickflow High Port Shaft Mount Rocker Arms by Scorpion Racing Products


Shaft Mount Rocker Arms

Fits the following heads:

  • AFR Renegade 165-220cc

  • Dart Pro 1 & Pro 1 CNC 165-220cc

  • Edelbrock -E Street 289-351W & Edelbrock RPM XT

  • Ford Motorsports Stock OEM 302W-351W

  • Trickflow High Port

  • Shaft Mount Endurance Series

  • 1.7 ratio

  • Includes Polylock

  • Set of 16










All Scorpion Rocker Arms Feature:

  • Lightweight 7000 Series Aerospace-grade
    Aluminum Bodies for Maximum Strength and Durability

  • Needle Bearing Fulcrum and Roller Tip

  • Centerless Ground Trunnion

  • Centerless Ground Pin & Roller

  • Burr-Free Thru Hole in Trunnion

  • Large Machined Seat

  • Thick Walled Adjusting Nut

  • Pedestals Machined from Solid Steel

  • Black Oxide Coated Steel Parts

  • Anodized for Additional Protection and Durability

  • 100% CNC Machined in the USA

  • Exclusive LIFETIME WARRANTY*


Scorpion Racing Products Trickflow Twisted Wedge .205 Right Offset

Scorpion's Exclusive Lifetime Warranty!

1.7 SBF AFR Renegade 165-220cc, Dart Pro 1 & Pro 1 CNC 165-220cc, Edelbrock -E Street 289-351W & Edelbrock RPM XT, Ford Motorsports Stock OEM 302W-351W, & Trickflow High Port

"

Additional Information

Weight 18.0 oz
Dimentions 23 x 12 x 2 in

Specsheet

Make Ford
Engine Type V8
Engine Family 289-302-351W
Mounting Style Shaft Mount
Adjustment Adjustable
Ratio 1.7
Stud Size
Offset 0.200 in
Self Aligning No
Head Type Trickflow High Port
Series Shaft Mount
